Kioti NS4710 HST
Main Features
Engine Gross Power: 44.9 hp ( 33.5 kW)
PTO Type: Independent
Transmission Type: Hydrostatic
Shuttle: None
Open Station (ROPS)
KIOTI ECO Engine Technology
Powerful HST Transmission
Single Lever Joystick
Hydraulic Independent PTO
Features
Ergonomic Joystick Lever
An ergonomically designed joystick lever for front loader operation is standard on NS Series tractors.
Twin HST Pedals
Twin HST pedals offer easy forward and reverse movement with smooth engagement, acceleration and deceleration. Pedal pressure is minimized which reduces operator fatigue during long hours of use.
Deluxe Suspension Seat
Ergonomically designed, adjustable suspension seat allows the operator to ride in comfort no matter what the task may be.
Hydraulic Independent PTO
The standard rear PTO is easily engaged by the simple turn of a knob. A safety interlock prevents the engine from starting when the PTO switch is left on. All models come standard with a selectable manual or automatic PTO option. When the Auto PTO is engaged, the PTO will automatically shut off when the 3-point control is raised, eliminating exposure to the running implements.
HST Cruise Control
HST Cruise system enables the tractor to maintain a steady speed as set by the operator.
Eco-Friendly Diesel Engine
The Common Rail Diesel Engine (CRDI) improves fuel efficiency while reducing noise levels. With this eco-friendly Tier 4 engine, the NS Series offers the operator a quiet work environment with powerful performance.
Power Steering
Hydrostatic power steering minimizes the effort required to make tight, repetitive turns.
Foldable ROPS
A fold-down roll bar allows operators to move into tight areas quickly and easily.
Simple Maintenance
KIOTI tractors are designed for easy maintenance. Liftable hoods and removable side panels allow convenient access for daily service checks. Maintaining your tractor for long life and high performance has never been easier.
Specifications
Transmission
Transmission Type
Hydrostatic
Main Gear
Hydrostatic
No. of Travel Speeds - Forward / Reverse
3 Range
Min. Travel Speed of Forward w/ Ag @ Engine rated speed
0 mph (0 km/h)
Max. Travel Speed of Forward w/ Ag @ Engine rated speed
17.5 mph (28.1 km/h)
Power Take-Off (PTO)
PTO Type Trans
Independent
PTO Power
36.3 hp (27.1 kW)
Rear PTO Speed
540 rpm
Mid PTO Speed
2,000 rpm (Optional)
Brakes and Clutch
Brakes
Wet Disc Type
Clutch
None
Dimensions w/ AG Tire
Length w/ 3-point hitch
136.4 in. (3,465 mm)
Width
67.1 in. (1,705 mm)
Height from Top of ROPS
98.4 in. (2,500 mm) w/o Beacon
Wheelbase
75.5 in. (1,918 mm)
Ground Clearance
13.4 in. (340 mm)
Front Tread Ag Tires - Min
51.1 in. (1,297 mm)
Rear Tread Ag Tires - Min
54.3 in. (1,380 mm)
Turning Radius w/ Brake
10.94 ft. (3.34 m)
Hydraulics
Pump Capacity (Max. Flow Rate)
16.5 gpm (62.4 L/min)
3-Point Hitch
Standard Category
Category I
Lift Capacity, 24" aft of hitch
2,493 lbs. (1,131 kg)
Control Type
Position with Draft Control
Equipment & Panel
Equipment & Panel
Standard Equipment
Optional Equipment
Instrument Panel
Rear PTO
Single Remote Hydraulic Valve
Wet Multi Disc Brakes
Joystick Valve
Drawbar
Headlights
Parking Brake
PTO cover
Sun Canopy
Beacon Light
Rear Working light
Front Weights
Mid PTO
HST Linked Pedal
Clevis Type Drawbar
Rear View Mirror (1ea)
Second Remote Hydraulic Valve (Non-Detent)
Second Remote Hydraulic Valve (Detent)
Fuel Heater Kit
Digital Hour Meter
Coolant Temperature Gauge
Electrical Tachometer
Fuel Gauge
Engine Oil Pressure Light
High Beam, Emergency Flasher, Direction Indicators
Glow Plug Light
Alternator Light
