- Engine Gross Power: 24.5 HP (18.2 kW)
- PTO Type: Live
- Transmission Type: Hydrostatic
- Shuttle: Dry Single Stage
- KIOTI Diesel Engine
- Hydrostatic Power Steering
- Hydrostatic Transmission
- Rear PTO
- Single Lever Joystick Standard
- Available with Field Option Cab
High Capacity Hydraulic Pump
The high capacity, efficient tandem hydraulic pump gives you smoother handling in heavy-duty working conditions and helps to reduce operator fatigue.
Responsive, powerful and comfortable steering reduces operator fatigue. The power steering system is robustly designed for maneuvering in soft soil and for front loader operation.
A fully adjustable suspension seat allows the operator to ride in comfort no matter what the job. A retractable seatbelt is standard on all KIOTI tractors to ensure operator safety.
Rear PTO is standard and mid PTO is optional. You can select the rear or mid PTO separately or simultaneously.
Single Lever Joystick
The operation of the front end loader is made easier by the use of a single lever joystick. The joystick allows you to perform all loader functions with a single lever. The lever automatically returns to neutral and the loader stops in place when the joystick is released. A float position allows the bucket free flotation over the ground surface.
A fold-down roll bar allows you to move into tight areas quickly and easily.
KIOTI tractors are designed for easy maintenance. Liftable hoods and removable side panels allow convenient access for daily service checks. Maintaining your tractor for long life and high performance has never been easier.
The center marker on the hood assists with maintaining straight rows.
High Ground Clearance
The minimum ground clearance of 13.4 in. makes usage on rocky or uneven terrain simpler.
The illuminated dashboard ensures great visibility while working in bright daylight or at night. The operator can check important instrumentation at a glance with an easy-to-see tachometer, hour meter, fuel temperature gauge and battery charge lamp.
3-Point Control Lever
The 3-point control lever allows you to easily raise and lower the lift arms when attaching implements.
HST Transmission with Twin HST Pedals
HST models feature performance proven, heavy-duty HST drives that deliver power and efficiently. The three range transmission (Hi/Mid/Low) with twin pedal operation makes your job easier, smoother and safer.
Transmission Type Hydrostatic No. of Travel Speeds - Forward / Reverse Infinite, 3 Range Min. Travel Speed of Forward w/ Ag @ Engine rated speed 0.75 mph (1.21 km/h) Max. Travel Speed of Forward w/ Ag @ Engine rated speed 9.79 mph (15.75 km/h)
Power Take-Off (PTO)
PTO Type Trans Live PTO Power 21.5 hp (16 kW) Rear PTO Speeds (1st) 540 rpm Mid PTO Speeds 2,000 rpm (Optional)
Brakes and Clutch
Brakes Wet Multi Disc Clutch Dry Single Stage
Dimensions w/ AG Tire
Length w/ 3-point hitch 120.9 in. (3,070 mm) Width 54.5 in. (1,385 mm) Height from Top of ROPS 92.91 in. (2,260 mm) Wheelbase 65.7 in. (1,670 mm) Ground Clearance 13.39 in. (340 mm) Front Tread Ag Tires - Min 48.2 in (1,225 mm) Rear Tread Ag Tires - Min 47.6 in. (1,210 mm) Min. Turning Radius w/ Brake 107 in. (2,730 mm)
Total Pump Flow 11.73 gpm (44.4 L/min)
Standard Category Category 1 Lift Capacity, 24" aft of hitch 1,631 lbs. (740 kg) Control Type Position
Weight w/ Ag Tires w/ ROPS 2,635 lbs. (1,195 kg)
Equipment & Panel
Equipment & Panel
Standard Equipment Optional Equipment Instrument Panel
- Rear PTO
- Wet Multi Disc Brakes
- Joystick Valve
- Parking Brake
- PTO Shield
- Front Weights
- Mid PTO
- HST Linked Pedal (HST Only)
- Clevis Type Drawbar
- Side View Mirror (1 ea)
- Dual Remote Hydraulic Valve (Non-Detent)
- Dual Remote Hydraulic Valve (Spring/Detent/Dual Detent)
- Fuel Heater Kit (N/A on CK2620)
- Rear Wheel Weight (Ag Tire Only)
- 3rd Function Kit for Front End Loader
- Digital Hour Meter
- Coolant Temperature Gauge
- Electrical Tachometer
- Fuel Gauge
- Engine Oil Pressure Light
- High Beam, Emergency Flasher, Direction Indicators
- Glow Plug Light
- Alternator Light
